NCAR AIRBORNE O2 INSTRUMENT RESULTS
PROJECT = ATOM4, FLIGHT = RF04, FILE = 180501a
PROCESSED Sat Feb 6 09:25:02 MST 2021

Notes
Logfile
All Periods Data
Calibration Data
Calibration Parameters
Assigned Cylinder Values
~ 0.5 Hz Measured Data File
1 Hz 10-sec Median Data File - plain text format
1 Hz Interpolated Data File - ICARTT format
1 Hz Interpolated Data File - ICARTT format - O2 adjusted / CO2 screened (from medcomp.r)

Results

Using data from 0 to 367 (Day of Year and Day Fraction)
Using data from 00:00:00 to 00:00:00 (HH:MM:SS)
Calibration gases:
HS: OK30762, CO2 (GMD) = 400.55, O2 (SIO) = -581.6
LS: OK30768, CO2 (GMD) = 423.55, O2 (SIO) = -822.5
LT: OK30772, CO2 (GMD) = 393.22, O2 (SIO) = -577
WT: OK30770, CO2 (GMD) = 409.36, O2 (SIO) = -855.2
LP: OK30769, CO2 (GMD) = 408.77, O2 (SIO) = -876.8
