NCAR O2 CO2 CALIBRATION FACILITY RESULTS
RUN = 250722a
PROCESSED Tue Jun 9 04:55:12 PM MDT 2026

Notes
Logfile

Results

Using data from 203.523 to 203.688 (Day of Year and Day Fraction)
(Position, CylinderID, SIO_CO2, SIO_CO2_sigma, SIO_CO2_slope, GMD_CO2, GMD_CO2_sigma, GMD_CO2_slope, CO2_n, d(O2/N2), d(O2/N2)_sigma, d(O2/N2)_slope, d(O2/N2)_n)

1 EN4325 406.633 0.011 0.194 406.496 0.011 0.189 4 NA NA NA NA
2 EN4329 423.800 0.016 0.261 423.234 0.015 0.254 4 NA NA NA NA
3 EN4328 415.500 0.017 0.314 415.142 0.017 0.307 4 NA NA NA NA
4 CC62120 459.392 0.028 0.511 457.936 0.027 0.498 4 NA NA NA NA
10 EN4330 406.617 0.001 -0.025 406.481 0.001 -0.025 3 NA NA NA NA
WT ND12480 404.804 0.032 0.669 404.713 0.032 0.653 31 NA NA NA NA
Text File

Raw Data and Diagnostics Figures

CO2 Timeseries
 CO2 Averages for Unknowns
 CO2 Averages for Knowns
Jog Ave. Diagnostics 1
 Jog Ave. Diagnostics 2
 Jog Std. Dev. Diagnostics
Jog Slope Diagnostics
 Rollover Effect
 Flushing Effect
CO2 Parameters
 CO2 Results
Residuals

Reference Cylinders, Assigned Concentrations, and Calculated Offsets from Fit

(Position, Cylinder ID, SIO CO2 in ppm, SIO Delta-CO2, SIO CO2 sigma, GMD CO2 in ppm, GMD Delta-CO2, GMD CO2 sigma, CO2 n, Plots)

5 CB08905 403.974 -0.049 0.002 403.890 -0.034 0.002 4    CO2 Fits 1    CO2 Fits 2
6 CC339490 451.644 -0.007 0.000 450.380 -0.005 0.000 4    CO2 Fits 1    CO2 Fits 2
9 CC339495 410.036 0.054 0.001 409.830 0.036 0.001 4    CO2 Fits 1    CO2 Fits 2

Measured Cylinders and Calculated Concentrations

(Position, Cylinder ID, Plots)
(Day of Year and Day Fraction, SIO CO2 in ppm, GMD CO2 in ppm, Plots)

1 EN4325    CO2 Fits 1    CO2 Fits 2
203.484 406.712 406.573
203.563 406.631 406.494
203.568 406.618 406.481
203.647 406.639 406.502
203.652 406.643 406.506

2 EN4329    CO2 Fits 1    CO2 Fits 2
203.479 423.954 423.384
203.489 423.948 423.379
203.557 423.778 423.213
203.573 423.803 423.237
203.641 423.804 423.238
203.657 423.815 423.249

3 EN4328    CO2 Fits 1    CO2 Fits 2
203.494 415.471 415.113
203.552 415.479 415.121
203.578 415.499 415.140
203.636 415.502 415.143
203.662 415.521 415.162

4 CC62120    CO2 Fits 1    CO2 Fits 2
203.500 459.475 458.018
203.547 459.359 457.904
203.584 459.388 457.933
203.631 459.395 457.939
203.668 459.427 457.971




10 EN4330    CO2 Fits 1
203.521 406.624 406.487
203.526 406.619 406.482
203.605 406.617 406.481
203.610 406.616 406.480
