NCAR AIRBORNE O2 INSTRUMENT RESULTS
PROJECT = ORCAS, FLIGHT = RF11, FILE = 160212a
PROCESSED Thu Nov 19 04:32:37 MST 2020

Notes
Logfile
All Periods Data
Calibration Data
Calibration Parameters
Assigned Cylinder Values
~ 0.5 Hz Measured Data File
1 Hz 10-sec Median Data File - plain text format
1 Hz Interpolated Data File - NASA Ames format
1 Hz Interpolated Data File - NASA Ames format - O2 adjusted / CO2 screened (from medcomp.r)

Results

Using data from 0 to 367 (Day of Year and Day Fraction)
Using data from 00:00:00 to 00:00:00 (HH:MM:SS)
Calibration gases:
HS: OK30771, CO2 (GMD) = 391.12, O2 (SIO) = -447.5
LS: OK30764, CO2 (GMD) = 403.83, O2 (SIO) = -708.8
LT: OK30772, CO2 (GMD) = 392.22, O2 (SIO) = -576.2
WT: OK30766, CO2 (GMD) = 377.8, O2 (SIO) = -521.2
LP: OK30770, CO2 (GMD) = 389.27, O2 (SIO) = -549
